-_DIP:1-10W_ASP20225

ASP20225

*The picture is for reference only, please refer to the actual product/technical specification for specific parameters

-

  • 型号：ASP20225
  • Rated power（W）: 20
  • Input voltage（V）: 85-265
  • Output current（mA）: 1100
  • Output voltage（V）: 18
  • Ambient temperature Max. (℃）: 60℃
  • Efficiency: 85.0%
  • 认证/标准: UL CB CE FCC
  • Isolation voltage（V）: 2000
  • Dimension (mm): 65.0x35.0x24.5
  • Winding No.: single
  • Package type: DIP
technical manual Sample Application
