Series Inductance DCR Load current Dimension (mm) Spec. Sample Application
</
FASNR3010
1.00-56.00uH 0.0850-3.0160Ω 210-1400mA -
-
FASNR3010-1R0N1R4
1.00uH 0.0850Ω 1400mA -
FASNR3010-1R2N1R25
1.20uH 0.0950Ω 1250mA -
FASNR3010-1R5N1R5
1.50uH 0.1040Ω 1270mA -
FASNR3010-2R2N1R15
2.20uH 0.1430Ω 1150mA -
FASNR3010-2R7N1R0
2.70uH 0.1690Ω 1000mA -
FASNR3010-3R3N0R97
3.30uH 0.1890Ω 970mA -
FASNR3010-3R6N0R95
3.60uH 0.2150Ω 950mA -
FASNR3010-4R7N0R75
4.70uH 0.2930Ω 750mA -
FASNR3010-5R6N0R58
5.60uH 0.3220Ω 580mA -
FASNR3010-6R8N0R55
6.80uH 0.3970Ω 550mA -
FASNR3010-8R2N0R55
8.20uH 0.5200Ω 550mA -
FASNR3010-100M0R55
10.00uH 0.5200Ω 550mA -
FASNR3010-120M0R43
12.00uH 0.6570Ω 430mA -
FASNR3010-150M0R42
15.00uH 0.7930Ω 420mA -
FASNR3010-220M0R35
22.00uH 1.2090Ω 350mA -
FASNR3010-270M0R3
27.00uH 1.4040Ω 300mA -
FASNR3010-330M0R29
33.00uH 2.0150Ω 290mA -
FASNR3010-390M0R28
39.00uH 2.2750Ω 280mA -
FASNR3010-430M0R23
43.00uH 2.3400Ω 230mA -
FASNR3010-470M0R22
47.00uH 2.5350Ω 220mA -
FASNR3010-510M0R21
51.00uH 2.8600Ω 210mA -
FASNR3010-560M0R21
56.00uH 3.0160Ω 210mA -
FASNR3012
0.22-100uH 0.0300-3.71801Ω 170-5300mA -
-
FASNR3012-1R0N1R87
1.00uH 0.0600Ω 1870mA -
FASNR3012-1R2N1R8
1.20uH 0.0720Ω 1800mA -
FASNR3012-1R5N1R62
1.50uH 0.0750Ω 1620mA -
FASNR3012-1R8N1R3
1.80uH 0.0980Ω 1300mA -
FASNR3012-2R2N1R2
2.20uH 0.1050Ω 1200mA -
FASNR3012-2R4N1R15
2.40uH 0.1100Ω 1150mA -
FASNR3012-2R7N1R14
2.70uH 0.1100Ω 1140mA -
FASNR3012-3R3N1R05
3.30uH 0.1400Ω 1050mA -
FASNR3012-3R6N1R05
3.60uH 0.1560Ω 1050mA -
FASNR3012-3R9N1R0
3.90uH 0.1560Ω 1000mA -
FASNR3012-4R7N0R9
4.70uH 0.1560Ω 900mA -
FASNR3012-5R6N0R8
5.60uH 0.2260Ω 800mA -
FASNR3012-6R8N0R75
6.80uH 0.2470Ω 750mA -
FASNR3012-100M0R6
10.00uH 0.3450Ω 600mA -
FASNR3012-101M0R21
100.00uH 3.7180Ω 210mA -
FASNR3012-120M0R48
12.00uH 0.4800Ω 480mA -
FASNR3012-150M0R45
15.00uH 0.4950Ω 450mA -
FASNR3012-180M0R43
18.00uH 0.7090Ω 430mA -
FASNR3012-220M0R42
22.00uH 0.8390Ω 420mA -
FASNR3012-270M0R35
27.00uH 1.1310Ω 350mA -
FASNR3012-330M0R36
33.00uH 1.1380Ω 360mA -
FASNR3012-360M0R34
36.00uH 1.2350Ω 340mA -
FASNR3012-390M0R3
39.00uH 1.7290Ω 300mA -
FASNR3012-470M0R27
47.00uH 1.8850Ω 270mA -
FASNR3012-560M0R26
56.00uH 1.9500Ω 260mA -
FASNR3012-680M0R24
68.00uH 2.1710Ω 240mA -
FASNR3012-820M0R17
82.00uH 3.3020Ω 170mA -
FASNR3012-R22N5R3
0.22uH 0.0300Ω 5300mA -
FASNR3012-R82N2R05
0.82uH 0.0500Ω 2050mA -
FASNR4018
0.47-220.00uH 0.0180-5.2000Ω 270-4900mA -
-
FASNR4018-1R0N4R8
1.00uH 0.0330Ω 4800mA -
FASNR4018-1R5N3R3
1.50uH 0.0460Ω 3300mA -
FASNR4018-1R5N3R35
1.50uH 0.0390Ω 3350mA -
FASNR4018-1R8N3R0
1.80uH 0.0440Ω 3000mA -
FASNR4018-2R2N2R7
2.20uH 0.0590Ω 2700mA -
FASNR4018-3R3N2R45
3.30uH 0.0910Ω 2450mA -
FASNR4018-4R7N1R7
4.70uH 0.1170Ω 1700mA -
FASNR4018-6R8N1R45
6.80uH 0.1430Ω 1450mA -
FASNR4018-100M1R3
10.00uH 0.2340Ω 1300mA -
FASNR4018-101M0R4
100.00uH 2.2750Ω 400mA -
FASNR4018-150M0R94
15.00uH 0.3250Ω 940mA -
FASNR4018-151M0R31
150.00uH 3.2500Ω 310mA -
FASNR4018-220M0R8
22.00uH 0.4680Ω 800mA -
FASNR4018-221M0R27
220.00uH 5.2000Ω 270mA -
FASNR4018-270M0R47
27.00uH 0.6110Ω 470mA -
FASNR4018-330M0R56
33.00uH 0.6890Ω 560mA -
FASNR4018-470M0R57
47.00uH 0.8450Ω 570mA -
FASNR4018-680M0R47
68.00uH 1.3000Ω 470mA -
FASNR4018-R47N4R3
0.47uH 0.0180Ω 4300mA -
FASNR4018-R68N4R9
0.68uH 0.0260Ω 4900mA -
FASNR4020
0.24-43.00uH 0.0140-0.8580Ω 770-10500mA -
-
FASNR4020-1R0N4R78
1.00uH 0.0380Ω 4780mA -
FASNR4020-1R2N5R1
1.20uH 0.0380Ω 5100mA -
FASNR4020-1R5N4R45
1.50uH 0.0460Ω 4450mA -
FASNR4020-2R2N3R4
2.20uH 0.0520Ω 3400mA -
FASNR4020-3R3N3R2
3.30uH 0.0910Ω 3200mA -
FASNR4020-3R6N2R8
3.60uH 0.0720Ω 2800mA -
FASNR4020-4R7N
4.70uH 0.0980Ω 2350mA -
FASNR4020-5R1N2R3
5.10uH 0.1110Ω 2300mA -
FASNR4020-5R6N2R2
5.60uH 0.1170Ω 2200mA -
FASNR4020-6R2N2R15
6.20uH 0.1500Ω 2150mA -
FASNR4020-6R8N2R2
6.80uH 0.1630Ω 2200mA -
FASNR4020-7R5N1R85
7.50uH 0.1500Ω 1850mA -
FASNR4020-8R2N1R75
8.20uH 0.1630Ω 1750mA -
FASNR4020-100M1R6
10.00uH 0.2150Ω 1600mA -
FASNR4020-120M1R5
12.00uH 0.2280Ω 1500mA -
FASNR4020-150M1R35
15.00uH 0.2990Ω 1350mA -
FASNR4020-220M1R05
22.00uH 0.4550Ω 1050mA -
FASNR4020-270M1R02
27.00uH 0.7090Ω 1020mA -
FASNR4020-330M0R85
33.00uH 0.7150Ω 850mA -
FASNR4020-390M0R82
39.00uH 0.8450Ω 820mA -
FASNR4020-430M0R77
43.00uH 0.8580Ω 770mA -
FASNR4020-R24N10R5
0.24uH 0.0140Ω 10500mA -
FASNR4020-R33N7R5
0.33uH 0.0160Ω 7500mA -
FASNR4020-R47N7R0
0.47uH 0.0290Ω 7000mA -
FASNR4020-R68N6R4
0.68uH 0.0360Ω 6400mA -
FASNR4026
1.0-33uH 0.031-0.3510Ω 550-3300mA -
-
FASNR4026-1R0N3R3
1.00uH 0.0310Ω 3300mA -
FASNR4026-1R2N3R1
1.20uH 0.0390Ω 3100mA -
FASNR4026-1R5N2R4
1.50uH 0.0390Ω 2400mA -
FASNR4026-2R2N2R1
2.20uH 0.0520Ω 2100mA -
FASNR4026-3R3N1R8
3.30uH 0.0650Ω 1800mA -
FASNR4026-4R7N1R45
4.70uH 0.0720Ω 1450mA -
FASNR4026-6R8N1R3
6.80uH 0.0850Ω 1300mA -
FASNR4026-100M1R0
10.00uH 0.1100Ω 1000mA -
FASNR4026-150M0R9
15.00uH 0.1430Ω 900mA -
FASNR4026-220M0R6
22.00uH 0.2140Ω 600mA -
FASNR4026-330M0R55
33.00uH 0.3510Ω 550mA -
FASNR4030
0.68-47uH 0.013-0.579Ω 950-6800mA -
-
FASNR4030-1R0N5R26
1.00uH 0.0180Ω 5260mA -
FASNR4030-1R2N5R8
1.20uH 0.0200Ω 5800mA -
FASNR4030-1R5N4R84
1.50uH 0.0260Ω 4840mA -
FASNR4030-1R8N5R4
1.80uH 0.0330Ω 5400mA -
FASNR4030-2R2N4R9
2.20uH 0.0390Ω 4900mA -
FASNR4030-3R3N3R3
3.30uH 0.0520Ω 3300mA -
FASNR4030-3R6N3R0
3.60uH 0.0520Ω 3000mA -
FASNR4030-3R9N3R0
3.90uH 0.0740Ω 3000mA -
FASNR4030-4R3N2R95
4.30uH 0.0720Ω 2950mA -
FASNR4030-4R7N2R9
4.70uH 0.0780Ω 2900mA -
FASNR4030-5R6N2R6
5.60uH 0.0850Ω 2600mA -
FASNR4030-6R8N2R75
6.80uH 0.1170Ω 2750mA -
FASNR4030-7R5N2R2
7.50uH 0.1100Ω 2200mA -
FASNR4030-8R2N2R1
8.20uH 0.1170Ω 2100mA -
FASNR4030-100M1R95
10.00uH 0.1300Ω 1950mA -
FASNR4030-120M1R7
12.00uH 0.1750Ω 1700mA -
FASNR4030-150M1R65
15.00uH 0.2470Ω 1650mA -
FASNR4030-180M1R4
18.00uH 0.2600Ω 1400mA -
FASNR4030-220M1R3
22.00uH 0.2920Ω 1300mA -
FASNR4030-270M1R15
27.00uH 0.3380Ω 1150mA -
FASNR4030-330M1R1
33.00uH 0.4290Ω 1100mA -
FASNR4030-360M1R05
36.00uH 0.4360Ω 1050mA -
FASNR4030-390M1R03
39.00uH 0.5660Ω 1030mA -
FASNR4030-470M0R95
47.00uH 0.5790Ω 950mA -
FASNR4030-R68N6R8
0.68uH 0.0130Ω 6800mA -
FASNR4030-R91N6R25
0.91uH 0.0170Ω 6250mA -
FASNR5020
0.22-200uH 0.0110-2.6000Ω 300-9000mA -
-
FASNR5020-1R0N4R1
1.00uH 0.0260Ω 4100mA -
FASNR5020-1R2N4R5
1.20uH 0.0290Ω 4500mA -
FASNR5020-1R5N4R1
1.50uH 0.0340Ω 4100mA -
FASNR5020-2R2N3R2
2.20uH 0.0420Ω 3200mA -
FASNR5020-2R7N2R9
2.70uH 0.0490Ω 2900mA -
FASNR5020-3R0N2R55
3.00uH 0.0490Ω 2550mA -
FASNR5020-3R3N2R55
3.30uH 0.0560Ω 2550mA -
FASNR5020-3R6N2R8
3.60uH 0.0560Ω 2800mA -
FASNR5020-3R9N2R3
3.90uH 0.0560Ω 2300mA -
FASNR5020-4R3N2R5
4.30uH 0.0740Ω 2500mA -
FASNR5020-4R7N2R5
4.70uH 0.0740Ω 2500mA -
FASNR5020-5R1N2R25
5.10uH 0.0830Ω 2250mA -
FASNR5020-5R6N2R3
5.60uH 0.0830Ω 2300mA -
FASNR5020-6R8N2R05
6.80uH 0.1080Ω 2050mA -
FASNR5020-7R5N1R85
7.50uH 0.1170Ω 1850mA -
FASNR5020-8R2N1R85
8.20uH 0.1270Ω 1850mA -
FASNR5020-9R1M1R7
9.10uH 0.1430Ω 1700mA -
FASNR5020-100M1R7
10.00uH 0.1430Ω 1700mA -
FASNR5020-101M0R53
100.00uH 1.4300Ω 530mA -
FASNR5020-120M1R5
12.00uH 0.1820Ω 1500mA -
FASNR5020-121M0R42
120.00uH 1.7550Ω 420mA -
FASNR5020-150M1R35
15.00uH 0.2150Ω 1350mA -
FASNR5020-180M1R25
18.00uH 0.2600Ω 1250mA -
FASNR5020-201M0R3
200.00uH 2.6000Ω 300mA -
FASNR5020-220M1R5
22.00uH 0.3900Ω 1500mA -
FASNR5020-330M0R92
33.00uH 0.5070Ω 920mA -
FASNR5020-470M0R77
47.00uH 0.6800Ω 770mA -
FASNR5020-560M0R77
56.00uH 0.8190Ω 770mA -
FASNR5020-680M0R65
68.00uH 0.9620Ω 650mA -
FASNR5020-820M0R65
82.00uH 1.1580Ω 650mA -
FASNR5020-R22N9R0
0.22uH 0.0110Ω 9000mA -
FASNR5020-R24N8R0
0.24uH 0.0110Ω 8000mA -
FASNR5020-R47N6R15
0.47uH 0.0170Ω 6150mA -
FASNR5020-R56N8R5
0.56uH 0.0220Ω 8500mA -
FASNR5020-R68N5R5
0.68uH 0.0220Ω 5500mA -
FASNR5020-R75N5R5
0.75uH 0.0220Ω 5500mA -
FASNR5040
1.0-1000uH 0.0160-7.8000Ω 210-7350mA -
-
FASNR5040-1R0N7R35
1.00uH 0.0160Ω 7350mA -
FASNR5040-1R2N6R5
1.20uH 0.0210Ω 6500mA -
FASNR5040-1R5N6R3
1.50uH 0.0200Ω 6300mA -
FASNR5040-1R8N5R5
1.80uH 0.0210Ω 5500mA -
FASNR5040-2R2N4R9
2.20uH 0.0250Ω 4900mA -
FASNR5040-2R7N4R3
2.70uH 0.0290Ω 4300mA -
FASNR5040-3R0N4R15
3.00uH 0.0290Ω 4150mA -
FASNR5040-3R3N3R95
3.30uH 0.0310Ω 3950mA -
FASNR5040-3R6N3R8
3.60uH 0.0340Ω 3800mA -
FASNR5040-3R9N3R55
3.90uH 0.0350Ω 3550mA -
FASNR5040-4R7N3R5
4.70uH 0.0390Ω 3500mA -
FASNR5040-5R6N3R0
5.60uH 0.0460Ω 3000mA -
FASNR5040-6R8N2R9
6.80uH 0.0560Ω 2900mA -
FASNR5040-8R2N2R7
8.20uH 0.0620Ω 2700mA -
FASNR5040-100M2R35
10.00uH 0.0830Ω 2350mA -
FASNR5040-101M0R75
100.00uH 0.7280Ω 750mA -
FASNR5040-102M0R21
1000.00uH 7.8000Ω 210mA -
FASNR5040-150M2R0
15.00uH 0.1120Ω 2000mA -
FASNR5040-151M0R65
150.00uH 0.9750Ω 650mA -
FASNR5040-220M1R6
22.00uH 0.1680Ω 1600mA -
FASNR5040-330M1R3
33.00uH 0.2440Ω 1300mA -
FASNR5040-470M1R1
47.00uH 0.3540Ω 1100mA -
FASNR5040-680M0R9
68.00uH 0.5200Ω 900mA -
FASNR6028
1.0-1000uH 0.0130-7.5400Ω 180-6500mA -
-
FASNR6028-1R0N5R75
1.00uH 0.0130Ω 5750mA -
FASNR6028-1R2N6R4
1.20uH 0.0170Ω 6400mA -
FASNR6028-1R5N6R0
1.50uH 0.0170Ω 6000mA -
FASNR6028-2R2N5R1
2.20uH 0.0260Ω 5100mA -
FASNR6028-2R7N3R8
2.70uH 0.0260Ω 3800mA -
FASNR6028-3R3N4R15
3.30uH 0.0330Ω 4150mA -
FASNR6028-4R7N3R0
4.70uH 0.0390Ω 3000mA -
FASNR6028-5R1N3R2
5.10uH 0.0560Ω 3200mA -
FASNR6028-6R2N3R05
6.20uH 0.0610Ω 3050mA -
FASNR6028-6R8N2R6
6.80uH 0.0610Ω 2600mA -
FASNR6028-8R2N2R3
8.20uH 0.0720Ω 2300mA -
FASNR6028-9R1M2R55
9.10uH 0.0960Ω 2550mA -
FASNR6028-100M2R04
10.00uH 0.0940Ω 2040mA -
FASNR6028-101M0R65
100.00uH 0.6500Ω 650mA -
FASNR6028-102M0R18
1000.00uH 7.5400Ω 180mA -
FASNR6028-120M1R8
12.00uH 0.1040Ω 1800mA -
FASNR6028-150M1R75
15.00uH 0.1630Ω 1750mA -
FASNR6028-180M1R52
18.00uH 0.1560Ω 1520mA -
FASNR6028-220M1R45
22.00uH 0.1820Ω 1450mA -
FASNR6028-270M1R5
27.00uH 0.2020Ω 1500mA -
FASNR6028-330M1R35
33.00uH 0.2410Ω 1350mA -
FASNR6028-331M
330.00uH 2.4000Ω 270mA -
FASNR6028-360M1R25
36.00uH 0.2800Ω 1250mA -
FASNR6028-390M1R25
39.00uH 0.2930Ω 1250mA -
FASNR6028-401M0R3
400.00uH 2.8080Ω 300mA -
FASNR6028-470M1R15
47.00uH 0.4100Ω 1150mA -
FASNR6028-560M1R05
56.00uH 0.4490Ω 1050mA -
FASNR6028-680M0R8
68.00uH 0.4680Ω 800mA -
FASNR6028-750M0R9
75.00uH 0.5330Ω 900mA -
FASNR6028-820M0R8
82.00uH 0.6500Ω 800mA -
FASNR6028-R82N6R5
0.82uH 0.0160Ω 6500mA -
FASNR6045
0.47-680.00uH 0.0080-3.25Ω 800-15000mA -
-
FASNR6045-1R0N9R85
1.00uH 0.0140Ω 9850mA -
FASNR6045-1R2N8R35
1.20uH 0.0130Ω 8350mA -
FASNR6045-1R3N8R35
1.30uH 0.0130Ω 8350mA -
FASNR6045-1R5N8R8
1.50uH 0.0130Ω 8350mA -
FASNR6045-1R8N7R6
1.80uH 0.0160Ω 7600mA -
FASNR6045-2R2N6R75
2.20uH 0.0180Ω 6750mA -
FASNR6045-2R3N6R0
2.30uH 0.0270Ω 6000mA -
FASNR6045-2R7N5R75
2.70uH 0.0200Ω 5750mA -
FASNR6045-3R0N5R6
3.00uH 0.0260Ω 5600mA -
FASNR6045-3R3N5R9
3.30uH 0.0270Ω 5900mA -
FASNR6045-3R6N5R25
3.60uH 0.0270Ω 5250mA -
FASNR6045-4R3N4R45
4.30uH 0.030Ω 4450mA -
FASNR6045-4R5N4R97
4.50uH 0.0340Ω 4970mA -
FASNR6045-4R7N4R97
4.70uH 0.0340Ω 4970mA -
FASNR6045-5R1N4R4
5.10uH 0.0340Ω 4400mA -
FASNR6045-5R6N4R15
5.60uH 0.0380Ω 4150mA -
FASNR6045-6R2N4R43
6.20uH 0.0400Ω 4430mA -
FASNR6045-6R3N4R43
6.30uH 0.0400Ω 4430mA -
FASNR6045-6R8N3R9
6.80uH 0.0400Ω 3900mA -
FASNR6045-7R5N3R5
7.50uH 0.0440Ω 3500mA -
FASNR6045-8R2N3R9
8.20uH 0.0560Ω 3900mA -
FASNR6045-9R1M3R35
9.10uH 0.0560Ω 3350mA -
FASNR6045-100M3R2
10.00uH 0.0620Ω 3200mA -
FASNR6045-120M2R8
12.00uH 0.0750Ω 2800mA -
FASNR6045-150M2R5
15.00uH 0.0880Ω 2500mA -
FASNR6045-180M2R2
18.00uH 0.1050Ω 2200mA -
FASNR6045-220M2R05
22.00uH 0.1160Ω 2050mA -
FASNR6045-221M0R8
220.00uH 1.4950Ω 800mA -
FASNR6045-270M1R9
27.00uH 0.1330Ω 1900mA -
FASNR6045-300M1R7
30.00uH 0.1720Ω 1700mA -
FASNR6045-330M1R65
33.00uH 0.1780Ω 1650mA -
FASNR6045-360M1R62
36.00uH 0.2250Ω 1620mA -
FASNR6045-390M1R5
39.00uH 0.2340Ω 1500mA -
FASNR6045-430M1R63
43.00uH 0.2600Ω 1630mA -
FASNR6045-470M1R4
47.00uH 0.2600Ω 1400mA -
FASNR6045-681M0R42
680.00uH 3.2500Ω 420mA -
FASNR6045-R47N15R0
0.47uH 0.0080Ω 15000mA -
FASNR6045-R56N15R0
0.56uH 0.0080Ω 15000mA -
FASNR6045-R68N11R0
0.68uH 0.0080Ω 11000mA -
FASNR6045-R82N10R35
0.82uH 0.0100Ω 10350mA -
FASNR8040
0.82-100uH 0.01-0.377Ω 1150-13800mA -
-
FASNR8040-1R0N9R85
1.00uH 0.0100Ω 9850mA -
FASNR8040-1R2N10R0
1.20uH 0.0130Ω 10000mA -
FASNR8040-1R5N8R15
1.50uH 0.0130Ω 8150mA -
FASNR8040-2R0N9R25
2.00uH 0.0160Ω 9250mA -
FASNR8040-2R2N7R1
2.20uH 0.0160Ω 7100mA -
FASNR8040-3R0N6R1
3.00uH 0.0180Ω 6100mA -
FASNR8040-3R3N6R5
3.30uH 0.0220Ω 6500mA -
FASNR8040-3R6N7R52
3.60uH 0.0220Ω 7520mA -
FASNR8040-3R9N5R75
3.90uH 0.0220Ω 5750mA -
FASNR8040-4R7N5R9
4.70uH 0.0250Ω 5900mA -
FASNR8040-5R1N4R7
5.10uH 0.0250Ω 4700mA -
FASNR8040-5R6N6R0
5.60uH 0.0270Ω 6000mA -
FASNR8040-6R2N4R45
6.20uH 0.0270Ω 4450mA -
FASNR8040-6R8N4R55
6.80uH 0.0310Ω 4550mA -
FASNR8040-8R2N4R2
8.20uH 0.0340Ω 4200mA -
FASNR8040-100M3R6
10.00uH 0.0380Ω 3600mA -
FASNR8040-101M1R15
100.00uH 0.3770Ω 1150mA -
FASNR8040-120M3R5
12.00uH 0.0530Ω 3500mA -
FASNR8040-150M2R95
15.00uH 0.0610Ω 2950mA -
FASNR8040-180M2R7
18.00uH 0.0690Ω 2700mA -
FASNR8040-220M2R4
22.00uH 0.0900Ω 2400mA -
FASNR8040-270M2R15
27.00uH 0.1010Ω 2150mA -
FASNR8040-330M2R05
33.00uH 0.1260Ω 2050mA -
FASNR8040-360M2R0
36.00uH 0.1330Ω 2000mA -
FASNR8040-390M1R95
39.00uH 0.1390Ω 1950mA -
FASNR8040-430M1R9
43.00uH 0.1470Ω 1900mA -
FASNR8040-470M1R75
47.00uH 0.1770Ω 1750mA -
FASNR8040-510M1R7
51.00uH 0.1850Ω 1700mA -
FASNR8040-560M1R55
56.00uH 0.1920Ω 1550mA -
FASNR8040-620M1R5
62.00uH 0.2370Ω 1500mA -
FASNR8040-680M1R45
68.00uH 0.2550Ω 1450mA -
FASNR8040-R82N13R5
0.82uH 0.0100Ω 13800mA -
FASNR8065
4.70-68.00uH 0.0220-0.2300Ω 2700-8500mA -
-
FASNR8065-4R7N8R5
4.70uH 0.0220Ω 8500mA -
FASNR8065-5R6N8R0
5.60uH 0.0260Ω 8000mA -
FASNR8065-6R8N7R5
6.80uH 0.0286Ω 4500mA -
FASNR8065-8R2N7R0
8.20uH 0.0310Ω 7000mA -
FASNR8065-100M6R6
10.00uH 0.0400Ω 6600mA -
FASNR8065-150M4R8
15.00uH 0.0620Ω 4800mA -
FASNR8065-220M4R3
22.00uH 0.0650Ω 4300mA -
FASNR8065-330M3R5
33.00uH 0.1180Ω 3500mA -
FASNR8065-470M3R0
47.00uH 0.1560Ω 3000mA -
FASNR8065-680M2R7
68.00uH 0.2300Ω 2700mA -
FASB0404SS
- 100Ω 3000mA 3.8*4.9*5
-
FASB0404SS-334R
- 100Ω 3000mA 3.8*4.9*5
FASB0604
- 60-120Ω 650-900mA 5.85*6.25*3.6
-
FASB0604-015
- 60Ω 900mA 5.85*6.25*3.6
FASB0604-025
- 65Ω 800mA 5.85*6.25*3.6
FASB0604-035
- 80Ω 700mA 5.85*6.25*3.6
FASB0604-045
- 120Ω 650mA 5.85*6.25*3.6
FALQH-1210
0.1-560uH 0.25-28.0Ω 40-700mA -
-
FALQH-1210-1R0M
1.00uH 0.5000Ω 445mA -
FALQH-1210-1R2M
1.20uH 0.6000Ω 425mA -
FALQH-1210-1R5M
1.50uH 0.6000Ω 400mA -
FALQH-1210-1R8M
1.80uH 0.7000Ω 390mA -
FALQH-1210-2R2M
2.20uH 0.8000Ω 370mA -
FALQH-1210-2R7M
2.70uH 0.9000Ω 320mA -
FALQH-1210-3R3M
3.30uH 1.0000Ω 300mA -
FALQH-1210-3R9M
3.90uH 1.1000Ω 290mA -
FALQH-1210-4R7K
4.70uH 1.2000Ω 270mA -
FALQH-1210-5R6K
5.60uH 1.3000Ω 250mA -
FALQH-1210-6R8K
6.80uH 1.5000Ω 240mA -
FALQH-1210-8R2K
8.20uH 1.6000Ω 225mA -
FALQH-1210-100K
10.00uH 1.8000Ω 190mA -
FALQH-1210-101K
100.00uH 7.0000Ω 80mA -
FALQH-1210-120K
12.00uH 2.0000Ω 180mA -
FALQH-1210-121K
120.00uH 8.0000Ω 75mA -
FALQH-1210-150K
15.00uH 2.2000Ω 170mA -
FALQH-1210-151K
150.00uH 9.3000Ω 70mA -
FALQH-1210-180K
18.00uH 2.5000Ω 165mA -
FALQH-1210-181K
180.00uH 10.2000Ω 65mA -
FALQH-1210-220K
22.00uH 2.8000Ω 150mA -
FALQH-1210-221K
220.00uH 11.8000Ω 65mA -
FALQH-1210-270K
27.00uH 3.1000Ω 125mA -
FALQH-1210-271K
270.00uH 12.5000Ω 65mA -
FALQH-1210-330K
33.00uH 3.5000Ω 115mA -
FALQH-1210-331K
330.00uH 13.0000Ω 65mA -
FALQH-1210-390K
39.00uH 3.9000Ω 110mA -
FALQH-1210-391K
390.00uH 22.0000Ω 50mA -
FALQH-1210-470K
47.00uH 4.3000Ω 100mA -
FALQH-1210-471K
470.00uH 24.7000Ω 45mA -
FALQH-1210-560K
56.00uH 4.9000Ω 85mA -
FALQH-1210-561K
560.00uH 28.0000Ω 40mA -
FALQH-1210-680K
68.00uH 5.5000Ω 80mA -
FALQH-1210-820K
82.00uH 6.2000Ω 70mA -
FALQH-1210-R10M
0.10uH 0.2500Ω 700mA -
FALQH-1210-R18M
0.18uH 0.2500Ω 650mA -
FALQH-1210-R27M
0.27uH 0.2500Ω 600mA -
FALQH-1210-R39M
0.39uH 0.2500Ω 530mA -
FALQH-1210-R56M
0.56uH 0.2500Ω 530mA -
FALQH-1210-R68M
0.68uH 0.2500Ω 470mA -
FALQH-1210-R82M
0.82uH 0.2500Ω 450mA -
FALQH-1812
1.0-2200uH 0.00094-30Ω 30-550mA -
-
FALQH-1812-1R0M
1.00uH 0.2000Ω 550mA -
FALQH-1812-1R2M
1.20uH 0.2500Ω 530mA -
FALQH-1812-1R5M
1.50uH 0.2800Ω 500mA -
FALQH-1812-1R8M
1.80uH 0.3000Ω 500mA -
FALQH-1812-2R2M
2.20uH 0.3000Ω 500mA -
FALQH-1812-2R7M
2.70uH 0.3200Ω 500mA -
FALQH-1812-3R3M
3.30uH 0.3500Ω 500mA -
FALQH-1812-3R9M
3.90uH 0.3800Ω 500mA -
FALQH-1812-4R7K
4.70uH 0.4000Ω 500mA -
FALQH-1812-5R6K
5.60uH 0.4700Ω 500mA -
FALQH-1812-6R8K
6.80uH 0.5000Ω 500mA -
FALQH-1812-8R2K
8.20uH 0.5600Ω 500mA -
FALQH-1812-100K
10.00uH 0.5600Ω 450mA -
FALQH-1812-101K
100.00uH 2.5000Ω 175mA -
FALQH-1812-102K
1000.00uH 25.000Ω 50mA -
FALQH-1812-120K
12.00uH 0.6200Ω 450mA -
FALQH-1812-121K
120.00uH 3.0000Ω 165mA -
FALQH-1812-122K
1200.00uH 30.0000Ω 45mA -
FALQH-1812-150K
15.00uH 0.7300Ω 390mA -
FALQH-1812-152K
1500.00uH 0.0370Ω 40mA -
FALQH-1812-180K
18.00uH 0.0082Ω 370mA -
FALQH-1812-181K
180.00uH 0.0045Ω 135mA -
FALQH-1812-182K
180.00uH 0.0450Ω 35mA -
FALQH-1812-220K
22.00uH 0.00094Ω 350mA -
FALQH-1812-221K
220.00uH 0.0054Ω 125mA -
FALQH-1812-222K
2200.00uH 0.0500Ω 30mA -
FALQH-1812-270K
27.00uH 0.0011Ω 330mA -
FALQH-1812-271K
270.00uH 0.0068Ω 115mA -
FALQH-1812-330K
33.00uH 0.0012Ω 310mA -
FALQH-1812-331K
330.00uH 0.0082Ω 100mA -
FALQH-1812-390K
39.00uH 0.0014Ω 280mA -
FALQH-1812-391K
390.00uH 0.0097Ω 90mA -
FALQH-1812-470K
47.00uH 0.0015Ω 250mA -
FALQH-1812-471K
470.00uH 0.0120Ω 80mA -
FALQH-1812-560K
56.00uH 0.0017Ω 225mA -
FALQH-1812-561K
560.00uH 0.0150Ω 70mA -
FALQH-1812-680K
68.00uH 0.0019Ω 225mA -
FALQH-1812-681K
680.00uH 0.0170Ω 65mA -
FALQH-1812-820K
82.00uH 0.0022Ω 185mA -
FALQH-1812-821K
820.00uH 0.0210Ω 60mA -
FALQH-2220
0.12-10000uH 0.0100-140.0000Ω 50-6000mA -
-
FALQH-2220-1R0M
1.00uH 0.0270Ω 4000mA -
FALQH-2220-1R5M
1.50uH 0.0310Ω 3700mA -
FALQH-2220-2R2M
2.20uH 0.0410Ω 3200mA -
FALQH-2220-3R3M
3.30uH 0.0500Ω 2900mA -
FALQH-2220-4R7M
4.70uH 0.0570Ω 2700mA -
FALQH-2220-6R8M
6.80uH 0.1000Ω 2000mA -
FALQH-2220-100K
10.00uH 0.1300Ω 1700mA -
FALQH-2220-101K
100.00uH 1.2000Ω 560mA -
FALQH-2220-102K
1000.00uH 14.4000Ω 150mA -
FALQH-2220-103K
10000.00uH 140.0000Ω 50mA -
FALQH-2220-150K
15.00uH 0.2100Ω 1400mA -
FALQH-2220-151K
150.00uH 2.6600Ω 420mA -
FALQH-2220-152K
1500.00uH 30.1000Ω 100mA -
FALQH-2220-220K
22.00uH 0.2700Ω 1200mA -
FALQH-2220-221K
220.00uH 3.3600Ω 320mA -
FALQH-2220-222K
2200.00uH 45.0000Ω 90mA -
FALQH-2220-330K
33.00uH 0.4500Ω 900mA -
FALQH-2220-331K
330.00uH 6.1600Ω 270mA -
FALQH-2220-332K
3300.00uH 50.0000Ω 80mA -
FALQH-2220-470K
47.00uH 0.5600Ω 800mA -
FALQH-2220-471K
470.00uH 7.5600Ω 240mA -
FALQH-2220-472K
4700.00uH 61.0000Ω 70mA -
FALQH-2220-680K
68.00uH 0.9400Ω 640mA -
FALQH-2220-681K
680.00uH 11.3000Ω 190mA -
FALQH-2220-682K
6800.00uH 100.0000Ω 60mA -
FALQH-2220-822K
8200.00uH 125.0000Ω 50mA -
FALQH-2220-R12M
0.12uH 0.0100Ω 6000mA -
FALQH-2220-R27M
0.27uH 0.0140Ω 5300mA -
FALQH-2220-R47M
0.47uH 0.0180Ω 4800mA -
FASDR0301
2.20-330uH 0.1300-16.0000Ω 900-790mA -
-
FASDR0301-2R2M0R79
2.20uH 0.1300Ω 790mA -
FASDR0301-3R3M0R75
3.30uH 0.1500Ω 750mA -
FASDR0301-4R7M0R65
4.70uH 0.1800Ω 650mA -
FASDR0301-100M0R45
10.00uH 0.3900Ω 450mA -
FASDR0301-101M0R15
100.00uH 2.8700Ω 150mA -
FASDR0301-150M0R3
15.00uH 0.7500Ω 300mA -
FASDR0301-220M0R25
22.00uH 0.9200Ω 250mA -
FASDR0301-221M0R13
220.00uH 10.0000Ω 130mA -
FASDR0301-330M0R20
33.00uH 1.4300Ω 200mA -
FASDR0301-331M0R09
330.00uH 16.0000Ω 90mA -
FASDR0301-470M0R17
47.00uH 1.6900Ω 170mA -
FASDR0301-680M0R16
68.00uH 2.7000Ω 160mA -
FASDR0302
1.00-680uH 0.0350-20.5000Ω 40-3200mA -
-
FASDR0302-1R0M3R2
1.00uH 0.0350Ω 3200mA -
FASDR0302-1R5M2R6
1.50uH 0.0750Ω 2600mA -
FASDR0302-2R2M2R35
2.20uH 0.1300Ω 2350mA -
FASDR0302-2R7M1R9
2.70uH 0.1400Ω 1900mA -
FASDR0302-3R3M1R8
3.30uH 0.1700Ω 1800mA -
FASDR0302-4R7M1R4
4.70uH 0.2100Ω 1400mA -
FASDR0302-5R6M1R2
5.60uH 0.2200Ω 1200mA -
FASDR0302-6R8M1R15
6.80uH 0.2500Ω 1150mA -
FASDR0302-100M1R1
10.00uH 0.3200Ω 1100mA -
FASDR0302-101K0R25
100.00uH 2.800Ω 250mA -
FASDR0302-120M0R85
12.00uH 0.3500Ω 850mA -
FASDR0302-150M0R8
15.00uH 0.4200Ω 800mA -
FASDR0302-151K0R2
150.00uH 4.2000Ω 200mA -
FASDR0302-220M0R65
22.00uH 0.5800Ω 650mA -
FASDR0302-221K0R16
220.00uH 6.0000Ω 160mA -
FASDR0302-270M0R5
27.00uH 0.6500Ω 500mA -
FASDR0302-330K0R45
33.00uH 0.8000Ω 450mA -
FASDR0302-331K0R12
330.00uH 9.5000Ω 120mA -
FASDR0302-391K0R11
390.00uH 10.5000Ω 110mA -
FASDR0302-470K0R4
47.00uH 1.2000Ω 400mA -
FASDR0302-471K0R95
470.00uH 11.5000Ω 95mA -
FASDR0302-560K0R31
56.00uH 1.6500Ω 310mA -
FASDR0302-680K0R29
68.00uH 1.8000Ω 290mA -
FASDR0302-681K0R04
680.00uH 20.5000Ω 40mA -
FASDR0403
1.00-2200.00uH 0.0300-30.0000Ω 20-3800mA -
-
FASDR0403-1R0M3R8
1.00uH 0.0300Ω 3800mA -
FASDR0403-1R5M3R5
1.50uH 0.0360Ω 3500mA -
FASDR0403-2R2M2R9
2.20uH 0.0470Ω 2900mA -
FASDR0403-2R7M2R5
2.70uH 0.0520Ω 2500mA -
FASDR0403-3R3M2R4
3.30uH 0.0580Ω 2400mA -
FASDR0403-3R9M1R98
3.90uH 0.0760Ω 1980mA -
FASDR0403-4R7M1R9
4.70uH 0.0940Ω 1900mA -
FASDR0403-5R6M1R8
5.60uH 0.1000Ω 1800mA -
FASDR0403-6R8M1R6
6.80uH 0.1200Ω 1600mA -
FASDR0403-8R2M1R26
8.20uH 0.1600Ω 1260mA -
FASDR0403-100M1R15
10.00uH 0.1800Ω 1150mA -
FASDR0403-101K0R4
100.00uH 1.5200Ω 400mA -
FASDR0403-102K0R13
1000.00uH 15.6000Ω 130mA -
FASDR0403-120M1R05
12.00uH 0.2100Ω 1050mA -
FASDR0403-150M0R92
15.00uH 0.2400Ω 920mA -
FASDR0403-151K0R38
150.00uH 2.0000Ω 380mA -
FASDR0403-180M0R84
18.00uH 0.3400Ω 840mA -
FASDR0403-220M0R76
22.00uH 0.3800Ω 760mA -
FASDR0403-221K0R32
220.00uH 3.4000Ω 320mA -
FASDR0403-222M0R02
2200.00uH 30.0000Ω 20mA -
FASDR0403-270M0R71
27.00uH 0.4100Ω 710mA -
FASDR0403-330K0R7
33.00uH 0.5100Ω 700mA -
FASDR0403-331K0R28
330.00uH 5.3000Ω 280mA -
FASDR0403-390K0R66
39.00uH 0.5600Ω 660mA -
FASDR0403-470K0R65
47.00uH 0.8000Ω 650mA -
FASDR0403-471K0R2
470.00uH 6.8000Ω 200mA -
FASDR0403-560K0R5
56.00uH 0.9400Ω 500mA -
FASDR0403-680K0R48
68.00uH 1.1200Ω 480mA -
FASDR0403-681K0R16
680.00uH 10.0000Ω 160mA -
FASDR0403-820K0R45
82.00uH 1.3500Ω 450mA -
FASDR0502
1-1000uH 0.021-15.0000Ω 140-4000mA -
-
FASDR0502-1R0M4R0
1.00uH 0.0210Ω 4000mA -
FASDR0502-1R5M4R0
1.50uH 0.0600Ω 4000mA -
FASDR0502-1R8M3R7
1.80uH 0.0650Ω 3700mA -
FASDR0502-2R2M3R5
2.20uH 0.0700Ω 3500mA -
FASDR0502-2R7M3R2
2.70uH 0.0800Ω 3200mA -
FASDR0502-3R3M2R7
3.30uH 0.1000Ω 2700mA -
FASDR0502-3R9M2R4
3.90uH 0.1200Ω 2400mA -
FASDR0502-4R7M2R0
4.70uH 0.1400Ω 2000mA -
FASDR0502-5R6M1R8
5.60uH 0.1500Ω 1800mA -
FASDR0502-6R8M1R5
6.80uH 0.1600Ω 1500mA -
FASDR0502-8R2M1R4
8.20uH 0.1700Ω 1400mA -
FASDR0502-100M1R3
10.00uH 0.2000Ω 1300mA -
FASDR0502-101K0R4
100.00uH 1.4000Ω 400mA -
FASDR0502-102K0R14
1000.00uH 15.0000Ω 140mA -
FASDR0502-120M1R1
12.00uH 0.2500Ω 1100mA -
FASDR0502-121K0R35
120.00uH 1.7500Ω 350mA -
FASDR0502-150M1R05
15.00uH 0.2500Ω 1050mA -
FASDR0502-151K0R25
150.00uH 2.0000Ω 250mA -
FASDR0502-180M1R0
18.00uH 0.3000Ω 1000mA -
FASDR0502-181K0R25
180.00uH 2.6000Ω 250mA -
FASDR0502-220M0R9
22.00uH 0.3500Ω 900mA -
FASDR0502-221K0R2
220.00uH 3.00Ω 200mA -
FASDR0502-270M0R85
27.00uH 0.4000Ω 850mA -
FASDR0502-271K0R18
270.00uH 3.7000Ω 180mA -
FASDR0502-330K0R75
33.00uH 0.5000Ω 750mA -
FASDR0502-331K0R17
330.00uH 4.3000Ω 170mA -
FASDR0502-390K0R7
39.00uH 0.5500Ω 700mA -
FASDR0502-391K0R16
390.00uH 6.0000Ω 160mA -
FASDR0502-470K0R6
47.00uH 0.6500Ω 600mA -
FASDR0502-471K0R15
470.00uH 6.7000Ω 150mA -
FASDR0502-560K0R55
56.00uH 0.7600Ω 550mA -
FASDR0502-680K0R5
68.00uH 0.9500Ω 500mA -
FASDR0502-820K0R45
82.00uH 1.2000Ω 450mA -
FASDR0503
1-1000uH 0.03-9.87Ω 100-4500mA -
-
FASDR0503-1R0M4R5
1.00uH 0.0300Ω 4500mA -
FASDR0503-1R5M4R2
1.50uH 0.0400Ω 4200mA -
FASDR0503-1R8M3R49
1.80uH 0.0500Ω 3490mA -
FASDR0503-2R2M3R12
2.20uH 0.0600Ω 3120mA -
FASDR0503-2R7M2R67
2.70uH 0.0700Ω 2670mA -
FASDR0503-3R3M2R51
3.30uH 0.0800Ω 2510mA -
FASDR0503-3R9M2R35
3.90uH 0.0900Ω 2350mA -
FASDR0503-4R7M2R14
4.70uH 0.1400Ω 2140mA -
FASDR0503-5R6M1R93
5.60uH 0.1500Ω 1930mA -
FASDR0503-6R8M1R82
6.80uH 0.1600Ω 1820mA -
FASDR0503-8R2M1R51
8.20uH 0.1700Ω 1510mA -
FASDR0503-100M1R3
10.00uH 0.1800Ω 1300mA -
FASDR0503-101K0R47
100.00uH 1.3000Ω 470mA -
FASDR0503-102K0R1
1000.00uH 9.8700Ω 100mA -
FASDR0503-120M1R27
12.00uH 0.2000Ω 1270mA -
FASDR0503-121K0R42
120.00uH 1.3800Ω 420mA -
FASDR0503-150M1R23
15.00uH 0.2200Ω 1230mA -
FASDR0503-151K0R35
150.00uH 1.8100Ω 350mA -
FASDR0503-180M1R17
18.00uH 0.2500Ω 1170mA -
FASDR0503-181K0R3
180.00uH 1.9500Ω 300mA -
FASDR0503-220M1R06
22.00uH 0.3500Ω 1060mA -
FASDR0503-221K0R28
220.00uH 2.1000Ω 280mA -
FASDR0503-270M0R85
27.00uH 0.4500Ω 850mA -
FASDR0503-271K0R23
270.00uH 2.4200Ω 230mA -
FASDR0503-330K0R8
33.00uH 0.5500Ω 800mA -
FASDR0503-331K0R19
330.00uH 3.8200Ω 190mA -
FASDR0503-390K0R78
39.00uH 0.7000Ω 780mA -
FASDR0503-391K0R16
390.00uH 4.6800Ω 160mA -
FASDR0503-470K0R75
47.00uH 0.7200Ω 750mA -
FASDR0503-471K0R15
470.00uH 5.1000Ω 150mA -
FASDR0503-560K0R56
56.00uH 0.8400Ω 560mA -
FASDR0503-561K0R14
560.00uH 6.0000Ω 140mA -
FASDR0503-680K0R52
68.00uH 0.9000Ω 520mA -
FASDR0503-681K0R13
680.00uH 7.6000Ω 130mA -
FASDR0503-820K0R5
82.00uH 0.9500Ω 500mA -
FASDR0503-821K0R11
820.00uH 9.1200Ω 110mA -
FASDR0504
1-2200uH 0.028-15Ω 100-4700mA -
-
FASDR0504-1R0M4R7
1.00uH 0.0250Ω 4700mA -
FASDR0504-1R4M4R4
1.40uH 0.0300Ω 4400mA -
FASDR0504-1R8M4R0
1.80uH 0.0350Ω 4000mA -
FASDR0504-2R2M3R2
2.20uH 0.0400Ω 3200mA -
FASDR0504-2R7M3R0
2.70uH 0.0450Ω 3000mA -
FASDR0504-3R3M2R8
3.30uH 0.0480Ω 2800mA -
FASDR0504-3R9M2R5
3.90uH 0.0550Ω 2500mA -
FASDR0504-4R7M2R4
4.70uH 0.0600Ω 2400mA -
FASDR0504-6R8M2R3
6.80uH 0.0650Ω 2300mA -
FASDR0504-100M1R44
10.00uH 0.0850Ω 1440mA -
FASDR0504-101K0R52
100.00uH 0.7000Ω 520mA -
FASDR0504-102K0R15
1000.00uH 7.0000Ω 150mA -
FASDR0504-120M1R4
120.00uH 0.1000Ω 1400mA -
FASDR0504-121K0R48
120.00uH 0.7700Ω 480mA -
FASDR0504-150M1R3
15.00uH 0.1200Ω 1300mA -
FASDR0504-151K0R46
150.00uH 1.2000Ω 460mA -
FASDR0504-152K0R12
1500.00uH 10.0000Ω 120mA -
FASDR0504-180M1R23
18.00uH 0.1500Ω 1230mA -
FASDR0504-182K0R11
1800.00uH 12.0000Ω 110mA -
FASDR0504-220M1R11
22.00uH 0.17000Ω 1110mA -
FASDR0504-221K0R42
220.00uH 1.5700Ω 420mA -
FASDR0504-222K0R1
2200.00uH 15.0000Ω 100mA -
FASDR0504-270M0R97
27.00uH 0.2000Ω 970mA -
FASDR0504-330K0R88
33.00uH 0.2300Ω 880mA -
FASDR0504-331K0R38
330.00uH 1.8000Ω 380mA -
FASDR0504-470K0R72
47.00uH 0.3500Ω 720mA -
FASDR0504-471K0R25
470.00uH 3.0000Ω 250mA -
FASDR0504-561K0R22
560.00uH 3.5000Ω 220mA -
FASDR0504-680K0R61
68.00uH 0.4600Ω 610mA -
FASDR0504-681K0R3
680.00uH 4.8000Ω 300mA -
FASDR0504-681K0R19
680.00uH 5.1000Ω 190mA -
FASDR0504-820K0R58
82.00uH 0.6000Ω 580mA -
FASDR0504-821K0R18
820.00uH 5.5000Ω 180mA -
FASDR0703
1.00-1000uH 0.0180-4.7600Ω 210-1640mA -
-
FASDR0703-1R0M1R64
1.00uH 0.0180Ω 1640mA -
FASDR0703-1R5M1R6
1.50uH 0.0200Ω 1600mA -
FASDR0703-2R2M1R6
2.20uH 0.0230Ω 1600mA -
FASDR0703-3R3M1R59
3.30uH 0.0250Ω 1590mA -
FASDR0703-4R7M1R54
4.70uH 0.0390Ω 1540mA -
FASDR0703-6R8M1R49
6.80uH 0.0400Ω 1490mA -
FASDR0703-8R2M1R46
8.20uH 0.0800Ω 1460mA -
FASDR0703-100M1R44
10.00uH 0.0800Ω 1440mA -
FASDR0703-101K0R51
100.00uH 0.4800Ω 510mA -
FASDR0703-102K0R2
1000.00uH 4.7600Ω 200mA -
FASDR0703-120M1R39
12.00uH 0.0900Ω 1390mA -
FASDR0703-121K0R49
120.00uH 0.5400Ω 490mA -
FASDR0703-150M1R24
15.00uH 0.1100Ω 1240mA -
FASDR0703-151K0R4
150.00uH 0.7600Ω 400mA -
FASDR0703-180M1R12
18.00uH 0.1100Ω 1120mA -
FASDR0703-181K0R36
180.00uH 1.0200Ω 360mA -
FASDR0703-220M1R07
22.00uH 0.1300Ω 1070mA -
FASDR0703-221K0R31
220.00uH 1.2000Ω 310mA -
FASDR0703-270M0R94
27.00uH 0.1500Ω 940mA -
FASDR0703-271K0R29
270.00uH 1.3100Ω 290mA -
FASDR0703-330K0R85
33.00uH 0.1700Ω 850mA -
FASDR0703-331K0R28
330.00uH 1.5000Ω 280mA -
FASDR0703-390K0R74
39.00uH 0.2200Ω 740mA -
FASDR0703-391K0R27
390.00uH 1.7000Ω 270mA -
FASDR0703-470K0R68
47.00uH 0.2500Ω 680mA -
FASDR0703-471K0R26
470.00uH 2.1000Ω 260mA -
FASDR0703-560K0R64
56.00uH 0.2800Ω 640mA -
FASDR0703-561K0R25
560.00uH 2.6600Ω 250mA -
FASDR0703-680K0R59
68.00uH 0.3300Ω 590mA -
FASDR0703-681K0R23
680.00uH 3.0000Ω 230mA -
FASDR0703-820K0R54
82.00uH 0.4100Ω 540mA -
FASDR0703-821K0R21
820.00uH 3.6300Ω 210mA -
FASDR0705
1.00-2200uH 0.0100-11.0000Ω 110-5500mA -
-
FASDR0705-1R0M5R5
1.00uH 0.0150Ω 5500mA -
FASDR0705-1R5M5R0
1.50uH 0.0180Ω 5000mA -
FASDR0705-2R2M4R5
2.20uH 0.0220Ω 4500mA -
FASDR0705-3R3M4R0
3.30uH 0.0300Ω 4000mA -
FASDR0705-4R7M3R6
4.70uH 0.0350Ω 3600mA -
FASDR0705-5R6M3R3
5.60uH 0.0380Ω 3300mA -
FASDR0705-6R8M3R1
6.80uH 0.0400Ω 3100mA -
FASDR0705-8R2M2R7
8.20uH 0.0500Ω 2700mA -
FASDR0705-100M2R3
10.00uH 0.0700Ω 2300mA -
FASDR0705-101K
100.00uH 0.4300Ω 720mA -
FASDR0705-102K0R2
1000.00uH 3.5000Ω 200mA -
FASDR0705-120M2R0
12.00uH 0.0800Ω 2000mA -
FASDR0705-121K0R66
120.00uH 0.4700Ω 660mA -
FASDR0705-150M1R8
15.00uH 0.0900Ω 1800mA -
FASDR0705-151K0R58
150.00uH 0.6400Ω 580mA -
FASDR0705-152K0R23
1.50uH 7.5000Ω 230mA -
FASDR0705-180M1R6
18.00uH 0.1000Ω 1600mA -
FASDR0705-181K0R51
180.00uH 0.7100Ω 510mA -
FASDR0705-220M1R5
22.00uH 0.1100Ω 1500mA -
FASDR0705-221K
220.00uH 0.9600Ω 490mA -
FASDR0705-222K0R15
2200.00uH 11.0000Ω 150mA -
FASDR0705-270M1R3
27.00uH 0.1200Ω 1300mA -
FASDR0705-271K0R45
270.00uH 1.1000Ω 450mA -
FASDR0705-330K1R2
33.00uH 0.1300Ω 1200mA -
FASDR0705-331K0R4
330.00uH 1.2600Ω 400mA -
FASDR0705-390K1R1
39.00uH 0.1600Ω 1100mA -
FASDR0705-470K
47.00uH 0.1800Ω 1100mA -
FASDR0705-471K0R33
470.00uH 1.8900Ω 330mA -
FASDR0705-560K0R94
56.00uH 0.2400Ω 940mA -
FASDR0705-561K0R32
560.00uH 2.0000Ω 320mA -
FASDR0705-680K0R85
68.00uH 0.2800Ω 850mA -
FASDR0705-681K0R26
680.00uH 2.5600Ω 260mA -
FASDR0705-820K0R78
82.00uH 0.3700Ω 780mA -
FASDR0705-821K0R22
820.00uH 3.2500Ω 220mA -
FASDR1004
1.00-560uH 0.0120-1.9000Ω 320-8700mA -
-
FASDR1004-1R0M8R7
1.00uH 0.0120Ω 8700mA -
FASDR1004-1R5M7R48
1.50uH 0.0160Ω 7480mA -
FASDR1004-1R8M6R8
1.80uH 0.0180Ω 6800mA -
FASDR1004-2R2M5R4
2.20uH 0.0200Ω 5400mA -
FASDR1004-2R7M3R2
2.70uH 0.0240Ω 3200mA -
FASDR1004-3R3M2R85
3.30uH 0.0280Ω 2850mA -
FASDR1004-3R9M2R8
3.90uH 0.0300Ω 2800mA -
FASDR1004-4R7M2R75
4.70uH 0.0380Ω 2750mA -
FASDR1004-5R6M2R7
5.60uH 0.0400Ω 2700mA -
FASDR1004-6R8M2R65
6.80uH 0.0420Ω 2650mA -
FASDR1004-8R2M2R6
8.20uH 0.0480Ω 2600mA -
FASDR1004-100M2R38
10.00uH 0.0530Ω 2380mA -
FASDR1004-101K0R74
100.00uH 0.3500Ω 740mA -
FASDR1004-120M2R13
12.00uH 0.0610Ω 2130mA -
FASDR1004-121K0R69
120.00uH 0.4000Ω 690mA -
FASDR1004-150M1R87
15.00uH 0.0700Ω 1870mA -
FASDR1004-151K0R61
150.00uH 0.5500Ω 610mA -
FASDR1004-180M1R73
18.00uH 0.0810Ω 1730mA -
FASDR1004-181K0R56
180.00uH 0.6200Ω 560mA -
FASDR1004-220M1R6
22.00uH 0.0900Ω 1600mA -
FASDR1004-221K0R53
220.00uH 0.7200Ω 530mA -
FASDR1004-270M1R44
27.00uH 0.1000Ω 1440mA -
FASDR1004-271K0R45
270.00uH 0.9500Ω 450mA -
FASDR1004-330K1R26
33.00uH 0.1200Ω 1260mA -
FASDR1004-331K0R42
330.00uH 1.1000Ω 420mA -
FASDR1004-390K1R2
39.00uH 0.1500Ω 1200mA -
FASDR1004-391K0R38
390.00uH 1.2500Ω 380mA -
FASDR1004-470K1R1
47.00uH 0.1700Ω 1100mA -
FASDR1004-471K0R35
470.00uH 1.5300Ω 350mA -
FASDR1004-560K1R01
56.00uH 0.2000Ω 1010mA -
FASDR1004-561K0R32
560.00uH 1.9000Ω 320mA -
FASDR1004-680K0R91
68.00uH 0.2200Ω 910mA -
FASDR1004-820K0R85
82.00uH 0.2500Ω 850mA -
FASDR1005
10.00-820.00uH 0.0600-2.5500Ω 240-2600mA -
-
FASDR1005-100M2R6
10.00uH 0.0600Ω 2600mA -
FASDR1005-101K0R97
100.00uH 0.3500Ω 970mA -
FASDR1005-120M2R45
12.00uH 0.0700Ω 2450mA -
FASDR1005-121K0R89
120.00uH 0.4000Ω 890mA -
FASDR1005-150M2R27
15.00uH 0.0800Ω 2270mA -
FASDR1005-151K0R78
150.00uH 0.4700Ω 780mA -
FASDR1005-180M2R15
18.00uH 0.0900Ω 2150mA -
FASDR1005-181K0R72
180.00uH 0.6300Ω 720mA -
FASDR1005-220M
22.00uH 0.1000Ω 1950mA -
FASDR1005-221K
220.00uH 0.7300Ω 660mA - -
FASDR1005-270M1R76
27.00uH 0.1100Ω 1760mA -
FASDR1005-330K
33.00uH 0.1200Ω 1500mA -
FASDR1005-331K0R52
330.00uH 1.1500Ω 520mA -
FASDR1005-390K1R37
39.00uH 0.1400Ω 1370mA -
FASDR1005-391K0R48
390.00uH 1.3000Ω 480mA -
FASDR1005-470K
47.00uH 0.1700Ω 1280mA -
FASDR1005-470M1R28
47.00uH 0.1700Ω 1280mA - -
FASDR1005-471K0R42
470.00uH 1.4800Ω 420mA -
FASDR1005-560K1R17
56.00uH 0.1900Ω 1170mA -
FASDR1005-561K0R33
560.00uH 1.9000Ω 330mA -
FASDR1005-680K
68.00uH 0.2200Ω 1110mA -
FASDR1006
1.00-1000.00uH 0.0080-3.0000Ω 460-9500mA -
-
FASDRH0703
1-1000uH 0.072-6.54Ω 160-7790mA -
-
FASDRH0703-1R0N7R79
1.00uH 0.0200Ω 7790mA - -
FASDRH0703-2R2N4R5
2.20uH 0.0260Ω 4500mA -
FASDRH0703-3R3N3R0
3.30uH 0.0400Ω 3000mA -
FASDRH0703-4R7N2R7
4.70uH 0.0430Ω 2700mA -
FASDRH0703-6R8N2R0
6.80uH 0.0600Ω 2000mA -
FASDRH0703-100M1R68
10.00uH 0.0720Ω 1680mA -
FASDRH0703-101M0R5
100.00uH 0.7900Ω 500mA -
FASDRH0703-102M0R16
1000.00uH 9.4400Ω 160mA -
FASDRH0703-120M1R52
12.00uH 0.0980Ω 1520mA -
FASDRH0703-121M0R49
120.00uH 0.8900Ω 490mA -
FASDRH0703-150M1R33
15.00uH 0.1300Ω 1330mA -
FASDRH0703-151M0R43
150.00uH 1.2700Ω 430mA -
FASDRH0703-180M1R2
18.00uH 0.1400Ω 1200mA -
FASDRH0703-181M0R39
180.00uH 1.4500Ω 390mA -
FASDRH0703-220M1R07
22.00uH 0.1900Ω 1070mA -
FASDRH0703-221M0R35
220.00uH 1.6500Ω 350mA -
FASDRH0703-270M0R96
27.00uH 0.2100Ω 960mA -
FASDRH0703-271M0R32
270.00uH 2.3100Ω 320mA -
FASDRH0703-330M0R91
33.00uH 0.2400Ω 910mA -
FASDRH0703-331M0R28
330.00uH 2.6200Ω 280mA -
FASDRH0703-390M0R8
39.00uH 0.3200Ω 800mA -
FASDRH0703-391M0R26
390.00uH 2.9400Ω 260mA -
FASDRH0703-470M0R76
47.00uH 0.3600Ω 760mA -
FASDRH0703-471M0R24
470.00uH 4.1800Ω 240mA -
FASDRH0703-560M0R68
56.00uH 0.4700Ω 680mA -
FASDRH0703-561M0R22
560.00uH 4.6700Ω 220mA -
FASDRH0703-680M0R61
68.00uH 0.5200Ω 610mA -
FASDRH0703-681M0R19
680.00uH 5.7300Ω 190mA -
FASDRH0703-820M0R57
82.00uH 0.6900Ω 570mA -
FASDRH0703-821M0R18
820.00uH 6.5400Ω 180mA -
FASDRH0704
1.00-1000.00uH 0.0180-6.0000Ω 180-8500mA -
-
FASDRH0704-1R0N8R5
1.00uH 0.0180Ω 8500mA -
FASDRH0704-2R2N5R0
2.20uH 0.0300Ω 5000mA -
FASDRH0704-3R3N3R5
3.30uH 0.0350Ω 3500mA -
FASDRH0704-4R7N3R0
4.70uH 0.0400Ω 3000mA -
FASDRH0704-4R7N4R0
4.70uH 0.0400Ω 4000mA -
FASDRH0704-6R8N2R5
6.80uH 0.0450Ω 2500mA -
FASDRH0704-100M1R84
10.00uH 0.0490Ω 1840mA -
FASDRH0704-101M0R6
100.00uH 0.6100Ω 600mA -
FASDRH0704-102M0R18
1000.00uH 6.000Ω 180mA -
FASDRH0704-120M1R71
12.00uH 0.0580Ω 1710mA -
FASDRH0704-121M0R52
120.00uH 0.6600Ω 520mA -
FASDRH0704-150M1R47
15.00uH 0.0810Ω 1470mA -
FASDRH0704-151M0R46
150.00uH 0.8800Ω 460mA -
FASDRH0704-180M1R31
18.00uH 0.0910Ω 1310mA -
FASDRH0704-181M0R42
180.00uH 0.9800Ω 420mA -
FASDRH0704-220M1R23
22.00uH 0.1100Ω 1230mA -
FASDRH0704-220M2R0
22.00uH 0.1340Ω 2000mA -
FASDRH0704-221M0R36
220.00uH 1.1700Ω 360mA -
FASDRH0704-270M1R12
27.00uH 0.1500Ω 1120mA -
FASDRH0704-271M0R34
270.00uH 1.6400Ω 340mA -
FASDRH0704-330M0R96
33.00uH 0.1700Ω 960mA -
FASDRH0704-331M0R32
330.00uH 1.8600Ω 320mA -
FASDRH0704-390M0R91
39.00uH 0.2300Ω 910mA -
FASDRH0704-391M0R29
390.00uH 2.8500Ω 290mA -
FASDRH0704-470M0R88
47.00uH 0.2600Ω 880mA -
FASDRH0704-471M0R26
470.00uH 3.0100Ω 260mA -
FASDRH0704-560M0R75
56.00uH 0.3500Ω 750mA -
FASDRH0704-561M0R23
560.00uH 3.6200Ω 230mA -
FASDRH0704-680M
68.00uH 0.3800Ω 690mA -
FASDRH0704-681M0R22
680.00uH 4.6300Ω 220mA -
FASDRH0704-820M0R61
82.00uH 0.4300Ω 610mA -
FASDRH0704-821M0R2
820.00uH 5.2000Ω 200mA -
FASDRH0704PC
4.70-22.00uH 0.0700-0.2200Ω 1230-3200mA - -
-
FASDRH0704CP-4R7M3R2
4.70uH 0.0700Ω 3200mA -
FASDRH0704PC-220M
22.00uH 0.2200Ω 1230mA -
FASDRH1204
1-330uH 0.008-0.990Ω 500-12000mA -
-
FASDRH1204-1R0N12R0
1.00uH 0.0080Ω 12000mA -
FASDRH1204-2R2N9R1
2.20uH 0.0120Ω 9100mA -
FASDRH1204-3R3N8R0
3.30uH 0.0150Ω 8000mA -
FASDRH1204-3R9N6R5
3.90uH 0.0170Ω 6500mA -
FASDRH1204-4R7N5R7
4.70uH 0.0180Ω 5700mA -
FASDRH1204-6R8N4R9
6.80uH 0.0230Ω 4900mA -
FASDRH1204-100M4R5
10.00uH 0.0400Ω 4500mA -
FASDRH1204-101M1R2
100.00uH 0.3100Ω 1200mA -
FASDRH1204-120M4R0
12.00uH 0.0380Ω 4000mA -
FASDRH1204-121M1R1
120.00uH 0.3800Ω 1100mA -
FASDRH1204-150M3R2
15.00uH 0.0500Ω 3200mA -
FASDRH1204-151M0R95
150.00uH 0.5300Ω 950mA -
FASDRH1204-180M3R1
18.00uH 0.0570Ω 3100mA -
FASDRH1204-181M0R85
180.00uH 0.6200Ω 850mA -
FASDRH1204-220M2R9
22.00uH 0.0660Ω 2900mA -
FASDRH1204-221M0R8
220.00uH 0.7000Ω 800mA -
FASDRH1204-270M2R8
27.00uH 0.0800Ω 2800mA -
FASDRH1204-271M0R6
270.00uH 0.8800Ω 600mA -
FASDRH1204-330M2R7
33.00uH 0.0970Ω 2700mA -
FASDRH1204-331M0R5
330.00uH 0.9900Ω 500mA -
FASDRH1204-390M2R1
39.00uH 0.1300Ω 2100mA -
FASDRH1204-470M1R9
47.00uH 0.1500Ω 1900mA -
FASDRH1204-560M1R8
56.00uH 0.1900Ω 1800mA -
FASDRH1204-680M1R5
68.00uH 0.2200Ω 1500mA -
FASDRH1204-820M1R3
82.00uH 0.2600Ω 1300mA -
FASDRH1205
1.00-1000.00uH 0.0070-1.5300Ω 400-15200mA -
-
FASDRH1205-1R0N15R2
1.00uH 0.0070Ω 15200mA -
FASDRH1205-3R3N8R0
3.30uH 0.0150Ω 8000mA -
FASDRH1205-4R7N7R6
4.70uH 0.0180Ω 7600mA -
FASDRH1205-6R8N5R5
6.80uH 0.0230Ω 5500mA -
FASDRH1205-8R2N5R0
8.20uH 0.0240Ω 5000mA -
FASDRH1205-100M4R0
10.00uH 0.0250Ω 4000mA -
FASDRH1205-101M1R3
100.00uH 0.1600Ω 1300mA -
FASDRH1205-102M0R4
1000.00uH 1.5300Ω 400mA -
FASDRH1205-120M3R5
12.00uH 0.0270Ω 3500mA -
FASDRH1205-121M1R1
120.00uH 0.1700Ω 1100mA -
FASDRH1205-150M3R3
15.00uH 0.0300Ω 3300mA -
FASDRH1205-151M1R0
150.00uH 0.2300Ω 1000mA -
FASDRH1205-180M3R0
18.00uH 0.0340Ω 3000mA -
FASDRH1205-181M0R9
180.00uH 0.2900Ω 900mA -
FASDRH1205-220M2R8
22.00uH 0.0360Ω 2800mA -
FASDRH1205-221M0R8
220.00uH 0.4000Ω 800mA -
FASDRH1205-270M2R3
27.00uH 0.0510Ω 2300mA -
FASDRH1205-271M0R75
270.00uH 0.4600Ω 750mA -
FASDRH1205-330M2R1
33.00uH 0.0570Ω 2100mA -
FASDRH1205-331M0R68
330.00uH 0.5100Ω 680mA -
FASDRH1205-390M2R0
39.00uH 0.0680Ω 2000mA -
FASDRH1205-391M0R65
390.00uH 0.6900Ω 650mA -
FASDRH1205-470M1R8
47.00uH 0.0750Ω 1800mA -
FASDRH1205-471M0R58
470.00uH 0.7700Ω 580mA -
FASDRH1205-560M1R7
56.00uH 0.1100Ω 1700mA -
FASDRH1205-561M0R54
560.00uH 0.8600Ω 540mA -
FASDRH1205-680M1R5
68.00uH 0.1200Ω 1500mA -
FASDRH1205-681M0R48
680.00uH 1.2000Ω 480mA -
FASDRH1205-820M1R4
82.00uH 0.1400Ω 1400mA -
FASDRH1205-821M0R43
820.00uH 1.3400Ω 430mA -
FASDRH1207
2.2-1000uH 0.012-1.640Ω 550-11500mA -
-
FASDRH1207-2R2N11R5
2.20uH 0.0120Ω 11500mA -
FASDRH1207-3R3N8R8
3.30uH 0.0140Ω 8800mA -
FASDRH1207-4R7N6R8
4.70uH 0.0160Ω 6800mA -
FASDRH1207-6R8N6R2
6.80uH 0.0200Ω 6200mA -
FASDRH1207-100M5R4
11.00uH 0.0220Ω 5400mA -
FASDRH1207-101M
100.00uH 0.2200Ω 1700mA -
FASDRH1207-102M0R55
1000.00uH 1.8200Ω 550mA -
FASDRH1207-120M4R9
12.00uH 0.0240Ω 4900mA -
FASDRH1207-121M1R6
120.00uH 0.2500Ω 1600mA -
FASDRH1207-150M4R5
15.00uH 0.0270Ω 4500mA -
FASDRH1207-151M1R42
150.00uH 0.2800Ω 1420mA -
FASDRH1207-180M3R9
18.00uH 0.0390Ω 3900mA -
FASDRH1207-181M1R3
180.00uH 0.3500Ω 1300mA -
FASDRH1207-220M3R6
22.00uH 0.0430Ω 3600mA -
FASDRH1207-221M
220.00uH 0.3900Ω 1160mA -
FASDRH1207-270M3R4
27.00uH 0.0460Ω 3400mA -
FASDRH1207-271M1R06
270.00uH 0.5600Ω 1060mA -
FASDRH1207-330M3R0
33.00uH 0.0650Ω 3000mA -
FASDRH1207-331M0R95
330.00uH 0.6400Ω 950mA -
FASDRH1207-390M2R75
39.00uH 0.0730Ω 2750mA -
FASDRH1207-391M0R88
390.00uH 0.7000Ω 880mA -
FASDRH1207-470M
47.00uH 0.1000Ω 2500mA -
FASDRH1207-471M0R79
470.00uH 0.9800Ω 790mA -
FASDRH1207-560M2R35
56.00uH 0.1100Ω 2350mA - -
FASDRH1207-561M0R73
560.00uH 1.0700Ω 730mA -
FASDRH1207-680M2R1
68.00uH 0.1400Ω 2100mA -
FASDRH1207-681M0R67
680.00uH 1.4600Ω 670mA -
FASDRH1207-820M1R95
82.00uH 0.1600Ω 1950mA -
FASDRH1207-821M0R6
820.00uH 1.6400Ω 600mA -
FASDRH1207P
22-22000uH 0.0430-42Ω 210-4500mA - -
-
FASDRH1207P-220M3R7
22.00uH 0.0430Ω 3700mA -
FASDRH1207P-223K
22000uH 42.0000Ω 210mA -
FASDRH1207P-390M
39uH 0.0770Ω 4500mA -
FASDRH1209
1.00-3300uH 0.0060-4.6Ω 370-19900mA - -
-
FASDRH1209-1R0N19R9
1.00uH 0.0060Ω 19900mA -
FASDRH1209-1R8N13R4
1.80uH 0.0070Ω 13400mA -
FASDRH1209-4R7N11R0
4.70uH 0.0110Ω 11000mA -
FASDRH1209-6R8N10R0
6.80uH 0.0120Ω 10000mA -
FASDRH1209-8R2N8R5
8.20uH 0.0150Ω 8500mA -
FASDRH1209-100M8R2
10.00uH 0.0170Ω 8200mA -
FASDRH1209-101M2R31
100.00uH 0.1300Ω 2310mA -
FASDRH1209-102M0R7
1000.00uH 1.2200Ω 700mA -
FASDRH1209-120M7R04
12.00uH 0.0190Ω 7040mA -
FASDRH1209-121M2R05
120.00uH 0.1500Ω 2050mA -
FASDRH1209-122M0R64
1200.00uH 1.3300Ω 640mA -
FASDRH1209-150M5R22
15.00uH 0.0250Ω 5220mA -
FASDRH1209-151M1R8
150.00uH 0.1700Ω 1800mA -
FASDRH1209-152M0R56
1500.00uH 1.9900Ω 560mA -
FASDRH1209-180M5R15
18.00uH 0.0270Ω 5150mA -
FASDRH1209-181M1R66
180.00uH 0.1900Ω 1660mA -
FASDRH1209-182M0R48
1800.00uH 2.1800Ω 480mA -
FASDRH1209-220M5R12
22.00uH 0.0290Ω 5120mA -
FASDRH1209-221M
220.00uH 0.3000Ω 2000mA -
FASDRH1209-221M1R64
220.00uH 0.2500Ω 1640mA -
FASDRH1209-221MZ
220.00uH 0.3000Ω 2200mA -
FASDRH1209-222M0R43
2200.00uH 2.5800Ω 430mA -
FASDRH1209-270M4R5
27.00uH 0.0450Ω 4500mA -
FASDRH1209-271M1R55
270.00uH 0.3000Ω 1550mA -
FASDRH1209-330M4R25
33.00uH 0.0530Ω 4250mA -
FASDRH1209-331M1R28
330.00uH 0.3900Ω 1280mA -
FASDRH1209-332M0R37
3300.00uH 4.6000Ω 370mA -
FASDRH1209-390M4R0
39.00uH 0.0560Ω 4000mA -
FASDRH1209-391M1R1
390.00uH 0.5000Ω 1100mA -
FASDRH1209-470M3R6
47.00uH 0.0630Ω 3600mA -
FASDRH1209-471M1R06
470.00uH 0.5500Ω 1060mA -
FASDRH1209-560M2R85
56.00uH 0.0680Ω 2850mA -
FASDRH1209-561M1R01
560.00uH 0.6500Ω 1010mA -
FASDRH1209-680M2R78
68.00uH 0.0930Ω 2760mA -
FASDRH1209-681M0R83
680.00uH 0.7300Ω 830mA -
FASDRH1209-820M2R62
82.00uH 0.0990Ω 2620mA -
FASDRH1209-821M0R81
820.00uH 0.8200Ω 810mA -
FASDRH6025
2.20-100.00uH 0.0320-0.6500Ω 330-1700mA -
-
FASDRH6025-2R2N1R7
2.20uH 0.0320Ω 1700mA -
FASDRH6025-4R7N1R5
4.70uH 0.0397Ω 1500mA -
FASDRH6025-5R6N1R4
5.60uH 0.0530Ω 1400mA -
FASDRH6025-6R8N1R3
6.80uH 0.0574Ω 1300mA -
FASDRH6025-100M1R0
10.00uH 0.0745Ω 1000mA -
FASDRH6025-101M0R33
100.00uH 0.6500Ω 330mA -
FASDRH6025-150M0R88
15.00uH 0.1100Ω 880mA -
FASDRH6025-220M0R73
22.00uH 0.1580Ω 730mA -
FASDRH6025-330M0R59
33.00uH 0.2340Ω 590mA -
FASDRH6025-470M0R48
47.00uH 0.3120Ω 480mA -
FASDRH6025-680M0R42
68.00uH 0.4810Ω 420mA -
FASDRH6028
4.70-220.00uH 0.0369-1.2740Ω 260-1600mA -
-
FASDRH6028-4R7N1R6
4.70uH 0.0369Ω 1600mA -
FASDRH6028-6R8N1R5
6.80uH 0.0460Ω 1500mA -
FASDRH6028-100M1R3
10.00uH 0.0691Ω 1300mA -
FASDRH6028-101M0R42
100.00uH 0.5590Ω 420mA -
FASDRH6028-150M1R0
15.00uH 0.0968Ω 1000mA -
FASDRH6028-151M0R34
150.00uH 0.8450Ω 340mA -
FASDRH6028-220M0R77
22.00uH 0.1350Ω 770mA -
FASDRH6028-221M0R26
220.00uH 1.2740Ω 260mA -
FASDRH6028-330M0R69
33.00uH 0.1920Ω 690mA -
FASDRH6028-470M0R59
47.00uH 0.2730Ω 590mA -
FASDRH6028-680M0R5
68.00uH 0.3770Ω 500mA -
FASDRH7032
3.3-680uH 0.0293-4.73Ω 160-1900mA -
-
FASDRH7032-3R3N1R9
3.30uH 0.0293Ω 1900mA -
FASDRH7032-4R7N1R7
4..70uH 0.0390Ω 1700mA -
FASDRH7032-6R8N1R6
6.80uH 0.0492Ω 1600mA -
FASDRH7032-100M1R4
10.00uH 0.0636Ω 1400mA -
FASDRH7032-101M0R45
100.00uH 0.5400Ω 450mA -
FASDRH7032-102M0R13
1000.00uH 4.7300Ω 1300mA -
FASDRH7032-150M1R1
15.00uH 0.0900Ω 1100mA -
FASDRH7032-151M0R37
150.00uH 0.7800Ω 370mA -
FASDRH7032-220M0R96
22.00uH 0.1320Ω 960mA -
FASDRH7032-221M0R29
220.00uH 1.2600Ω 290mA -
FASDRH7032-330M0R75
33.00uH 0.1920Ω 750mA -
FASDRH7032-331M0R22
330.00uH 2.0040Ω 220mA -
FASDRH7032-470M0R67
47.00uH 0.2880Ω 670mA -
FASDRH7032-471M0R2
470.00uH 2.4600Ω 200mA -
FASDRH7032-680M0R59
68.00uH 0.3720Ω 590mA -
FASDRH7032-681M0R16
680.00uH 3.7800Ω 160mA -
FASDRH7045
1-1000uH 0.018-2.736Ω 140-3500mA -
-
FASDRH7045-1R0N3R5
1.00uH 0.0180Ω 3500mA -
FASDRH7045-2R2N3R0
2.20uH 0.0228Ω 3000mA -
FASDRH7045-3R3N2R5
3.30uH 0.0240Ω 2500mA -
FASDRH7045-4R7N2R0
4.70uH 0.0360Ω 2000mA -
FASDRH7045-6R8N1R7
6.80uH 0.0468Ω 1700mA -
FASDRH7045-100M1R3
10.00uH 0.0504Ω 1300mA -
FASDRH7045-101M0R5
100.00uH 0.3000Ω 500mA -
FASDRH7045-102M0R14
1000.00uH 2.7360Ω 140mA -
FASDRH7045-150M1R1
15.00uH 0.0624Ω 1100mA -
FASDRH7045-151M0R4
150.00uH 0.4080Ω 400mA -
FASDRH7045-220M0R9
22.00uH 0.0732Ω 900mA -
FASDRH7045-221M0R33
220.00uH 0.6240Ω 330mA -
FASDRH7045-330M0R82
33.00uH 0.1160Ω 820mA -
FASDRH7045-331M0R25
330.00uH 0.8880Ω 250mA -
FASDRH7045-470M0R75
47.00uH 0.1500Ω 750mA -
FASDRH7045-471M0R22
470.00uH 1.2600Ω 220mA -
FASDRH7045-680M0R6
68.00uH 0.2100Ω 600mA -
FASDRH7045-681M0R2
680.00uH 1.7760Ω 200mA -
FASDRH7055
1.5-100uH 0.0226-0.381Ω 900-6200mA - -
-
FASDRH7055-1R5N6R2
1.50uH 0.0226Ω 6200mA -
FASDRH7055-2R2N5R3
2.20uH 0.0282Ω 5300mA -
FASDRH7055-3R3N4R3
3.30uH 0.0312Ω 4300mA -
FASDRH7055-3R9N4R0
3.90uH 0.0338Ω 4000mA -
FASDRH7055-4R7N3R6
4.70uH 0.0364Ω 3600mA -
FASDRH7055-6R8N3R0
6.80uH 0.0442Ω 3000mA -
FASDRH7055-100M2R6
10.00uH 0.0508Ω 2600mA -
FASDRH7055-101M0R8
100.00uH 0.3810Ω 1800mA -
FASDRH7055-150M2R1
15.00uH 0.0660Ω 2100mA -
FASDRH7055-180M1R9
18.00uH 0.0740Ω 1900mA -
FASDRH7055-220M1R7
22.00uH 0.0836Ω 1700mA -
FASDRH7055-330M1R4
33.00uH 0.1140Ω 1400mA -
FASDRH7055-470M1R2
47.00uH 0.1690Ω 1200mA -
FASDRH7055-680M0R9
68.00uH 0.2600Ω 900mA -
FASDRH103
1.50-150uH 0.0110-0.8710Ω 840-8000mA -
-
FASDRH103-1R5N8R0
1.50uH 0.0110Ω 8000mA -
FASDRH103-2R2N6R7
2.20uH 0.0170Ω 6700mA -
FASDRH103-3R3N5R56
3.30uH 0.0210Ω 5560mA -
FASDRH103-4R7N4R65
4.70uH 0.0300Ω 4650mA -
FASDRH103-6R8N3R84
6.80uH 0.0350Ω 3840mA -
FASDRH103-8R2N3R54
8.20uH 0.0500Ω 3540mA -
FASDRH103-100M3R18
10.00uH 0.0590Ω 3180mA -
FASDRH103-101M1R02
100.00uH 0.6830Ω 1020mA -
FASDRH103-121M0R89
120.00uH 0.7540Ω 890mA -
FASDRH103-150M2R6
15.00uH 0.0910Ω 2600mA -
FASDRH103-151M0R84
150.00uH 0.8710Ω 840mA -
FASDRH103-220M2R16
22.00uH 0.1430Ω 2160mA -
FASDRH103-330M1R74
33.00uH 0.2020Ω 1740mA -
FASDRH103-470M1R43
47.00uH 0.2990Ω 1430mA -
FASDRH103-560M1R36
56.00uH 0.3250Ω 1360mA -
FASDRH103-680M1R22
68.00uH 0.4290Ω 1220mA -
FASDRH103-820M1R14
82.00uH 0.4940Ω 1140mA -
FASDRH104
1-1000uH 0.0075-4.4200Ω 400-10500mA -
-
FASDRH104-1R0N10R5
1.00uH 0.0075Ω 10500mA -
FASDRH104-1R5N9R5
1.50uH 0.0085Ω 9500mA -
FASDRH104-1R8N9R0
1.80uH 0.0095Ω 9000mA -
FASDRH104-2R2N7R5
2.20uH 0.0105Ω 7500mA -
FASDRH104-2R5N7R5
2.50uH 0.0105Ω 7500mA -
FASDRH104-3R3N6R0
3.30uH 0.0130Ω 6000mA -
FASDRH104-3R8N6R0
3.80uH 0.0150Ω 6000mA -
FASDRH104-4R7N5R7
4.70uH 0.0200Ω 5700mA -
FASDRH104-5R2N5R5
5.20uH 0.0230Ω 5500mA -
FASDRH104-5R6N5R0
5.60uH 0.0270Ω 5000mA -
FASDRH104-6R8N5R0
6.80uH 0.0270Ω 5000mA -
FASDRH104-7R0N4R8
7.00H 0.0270Ω 4800mA -
FASDRH104-8R2N4R5
8.20uH 0.0330Ω 4500mA -
FASDRH104-100M4R4
10.00uH 0.0350Ω 4400mA -
FASDRH104-101M1R35
100.00uH 0.3040Ω 1350mA -
FASDRH104-102M0R4
1000.00uH 4.4200Ω 400mA -
FASDRH104-120M4R0
12.00uH 0.0460Ω 4000mA -
FASDRH104-121M1R18
120.00uH 0.4200Ω 1180mA -
FASDRH104-150M3R6
15.00uH 0.0500Ω 3600mA -
FASDRH104-151M1R15
150.00uH 0.5060Ω 1150mA -
FASDRH104-180M3R1
18.00uH 0.0700Ω 3100mA -
FASDRH104-181M1R0
180.00uH 0.6800Ω 1000mA -
FASDRH104-220M2R9
22.00uH 0.0730Ω 2900mA -
