MIS Flagship ( Single-Phase )

MIS75
MIS120
MIS240
MIS480
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Input voltage(V)

  • Output current(A)

  • Output current(mA)

  • Output voltage(V)

  • Efficiency

  • PFC function

  • DC-OK

  • Certificate

  • Spec.

  • Ripple and noise

  • Series

MIS Flagship ( Single-Phase ) Filter Models: 4 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(A) Output voltage(V) Efficiency PFC function DC-OK Certificate Spec. Sample Application
MIS75
75 90-264 - 12 24 48 - YES YES UL CE CB TUV SAA UKCA
-
MIS75-12
60 90-264 6.3 12 89% YES YES UL CE CB TUV SAA UKCA -
MIS75-24
75 90-264 3.2 24 89% YES YES UL CE CB TUV SAA UKCA -
MIS75-48
75 90-264 1.6 48 90% YES YES UL CE CB TUV SAA UKCA -
MIS120
120 90-264 - 12 24 48 - YES YES UL CE CB TUV SAA UKCA
-
MIS120-12
96 90-264 10 12 89% YES YES UL CE CB TUV SAA UKCA -
MIS120-24
120 90-264 5 24 91% YES YES UL CE CB TUV SAA UKCA -
MIS120-48
120 90-264 2.5 48 91% YES YES UL CE CB TUV SAA UKCA -
MIS240
240 90-264 - 24 48 - YES YES UL CE CB TUV SAA UKCA
-
MIS240-24
240 90-264 10 24 94% YES YES UL CE CB TUV SAA UKCA -
MIS240-48
240 90-264 5 48 94% YES YES UL CE CB TUV SAA UKCA -
MIS480
480 90-264 - 24 48 - YES YES UL CE CB TUV SAA UKCA
-
MIS480-24
480 90-264 20 24 94% YES YES UL CE CB TUV SAA UKCA -
MIS480-48
480 90-264 10 48 94% YES YES UL CE CB TUV SAA UKCA -

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
